Enter/Exit Programming Mode
Product Reference Guide
267
Quantity/Code Send Mode
This feature defines the rules that will be used to send a QTY/CODE pair:
0. Code is transmitted with QTY field (and its predefined format) preceding
CODE field (and its predefined format)
1. Code is transmitted with CODE field (and its pr
edefined format) preceding QTY
field (and its predefined format)
2. Code in CODE field is sent out for the number of times defined in the QTY field
Qty precedes Code
Code precedes Qty
Code transmitted Qty times
Quantity/Code Separator
This feature allows the insertion of a separator between Qty/Code pairs.
DEFAULT
No separator
Set Qty/Code string separator
To configure this feature, scan the ENTER/EXIT
PROGRAMMING MODE bar code above, then the
barcode at left followed by the digits (in Hex) from
Appendix D, representing your desired character(s).
If less than the expected string of 8 characters are
se
lected, scan the Enter/Exit bar code to terminate
the string. Exit programming mode by scanning the
ENTER/Exit bar code again.
To Next Page
