Datalogic PowerScan PD9531-AR User Manual

Performance Characteristics
Light Source LED
Roll (Tilt) Tolerance ± 180°
Pitch Tolerance ± 80°
Skew (Yaw) Tolerance ± 60°
Field of View 14° x 10.5° up to 1 m. Over 3 m: 14.4° x 10.8
Print Contrast
Minimum
15% minimum reflectance
Resolution
Max resolution 1D 3 mils
Max resolution 2D 4 mils
Depth of Field (Typical)
a
Symbology
Code 39
10 mils: 15 - 160 cm
40 mils: 50 - 1100 cm
55 mils: 70 - 1150 cm
100 mils: up to 2300 cm
EAN 13 mag. 1:20 - 290 cm
EAN 128
15 mils: 30 - 330 cm
40 mils: 60 - 850 cm
100 mils: up to 2000 cm
DataMatrix
10 mils: 20 - 85 cm
55 mils: 30 - 550 cm
100 mils: 30 - 880 cm
200 mils: up to 2000 cm
a
All labels grade A,300 lux ambient light, 20° C, label inclination 10°
Technical Specifications
314 PowerScan™ PD9531-AR/PBT9501-AR/PM9501-AR
