RF Programming Manual 7
Software Verify that your unit supports the desired interface
1
. The list below
indicates the interface groupings supported. Contact your nearest Dat-
alogic service depot if you don’t know your unit’s group, or need assis-
tance to change the unit to another interface group.
The Standard Keyboard Wedge/Wand Em./RS-232 Group supports:
• I/F Type A — PC/XT w/Alternate Key Encoding
• I/F Type B — AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 &
95 w/Alternate Key Encoding
• I/F Type C — PS/2 25 and 30 w/Alternate Key Encoding
• I/F Type D — PC/XT w/Standard Key Encoding
• I/F Type E — AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 &
95 w/Standard Key Encoding
• I/F Type F — PS/2 25 and 30 w/Standard Key Encoding
• I/F Type H — IBM
®
3xxx w/102 keyboard
• I/F Type I — PS/555530T w/104 keyboard
• I/F Type J — NEC
®
9801 keyboard
• Wand Emulation
• RS-232
• WN
2
—RS-232 (SNI)
The IBM/RS-232 Group supports:
The Universal [Keyboard] Wedge Group:
• Consult the Universal Wedge Connectivity Guide
3
for more infor-
mation.
• For additional configuration/programming, refer to the Uni-
versal Wedge Programming Guide3.
1. Contact your dealer or sales representative if your desired interface is not listed. Interface group
definitions are subject to change without notice.
2. Wincor Nixdorf
®
(formally SNI)
• IBM Port 5B • IBM Port E
• IBM Port 9B • RS-232
• IBM Port 17 • WN-RS-232
3. Contact your dealer or visit the website listed on the back cover of this manual for publications.
