Datamax E-Class Mark II Programmer's Manual

Appendix G – Bar Code Details
210 Class Series 2 Programmer’s Manual
The following example prints a 5 digit UPC bar code addendum:
<STX>L
D11<CR>
1N000000015010001234<CR>
121100000000100Barcode N<CR>
E
O: Code 93
Valid Characters: 0-9, A-Z, -.$/+% and the space character.
Variable Length.
Valid bar widths: The width multiplier is the width of the narrow bar in dots. All other
bars are a ratio of the narrow bar (2 times, 3 times, and 4 times the narrow bar width).
The following example prints a Code 93 bar code:
<STX>L
D11<CR>
1O0000000150100Datamax42<CR>
121100000000100Barcode O<CR>
E
p: Postnet
Valid Characters: 0-9
Length: 5, 9 or 11 digits
Valid bar widths: The width and height multiplier values of 00 will produce a valid
Postnet symbol.
Usage: The bar code height field is ignored since the symbol height is United States
Postal Service specific. This bar code is to display the zip code on a letter or package for
the US Postal Service.
The following example prints a Postnet bar code:
<STX>L
D11<CR>
1p000000015010032569<CR>
121100000000100Barcode p<CR>
E

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
