Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 39
STX K}M Manual Media Calibration (Non-Display Models only)
This command causes the printer to save the sampled calibration values as an operator
places different portions of label stock within the media sensor. Depending upon the
printer model, different front panel LED flash sequences and printer responses (below)
will indicate calibration progress and outcome; see the corresponding printer operator
manual for LED flash sequences details. Sending <ESC> to the printer instead of <CR>
will terminate the process and leave the TOF Sensor values unchanged.
Printer Response Alternate
LOAD STOCK[CR]
ENTER TO CONTINUE[CR]
N/A
LOAD MARK[CR]
ENTER TO CONTINUE[CR]
LOAD GAP[CR]
REMOVE STOCK[CR]
ENTER TO CONTINUE[CR]
N/A
PASSED CALIBRATION[CR] FAILED CALIBRATION[CR]
STX K}Q Quick Media Calibration (Non-Display Models only)
This command causes the printer to move media, sample, and then save sensor samples
as calibration values. This calibration function should be performed with media installed
in the printer. Depending upon the printer model, different front panel LED flash
sequences and printer responses (below) will indicate calibration progress and outcome;
see the corresponding printer operator manual for LED flash sequences details.
Printer Response Alternate
FAILED CALIBRATION[CR]
ADJUST GAIN SETTING[CR]
N/A
PASSED CALIBRATION[CR] FAILED CALIBRATION[CR]

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
