Class Series 2 Programmer’s Manual 185
Appendix E
Single Byte Symbol Sets
The following tables include some of the sixty-six standard symbol sets. Not all of these
symbol sets can be used with every font. Symbol sets containing the Euro currency
character are W1, WE, WG, WL, WT, WR, and PM; see Appendix I, and the <STX>y
command.

The following sets were produced using a Windows -based PC-compatible with a United
States keyboard properties layout. Results may vary if printing this document using a
different input locale.
(DN) ISO 60: Danish / Norwegian Symbol Set
0 1 2 3 4 5 6 7 8 9 A B C D E F
00
10
20 ! “ # $ % & ‘ ( ) * + , - . /
30 0 1 2 3 4 5 6 7 8 9 : ; < = > ?
40 @ A B C D E F G H I J K L M N O
50 P Q R S T U V W X Y Z Æ Ø Å ^ _
60 ‘ a b c d e f g h i j k l m n o
70 p q r s t u v w x y z æ ø å ¯
▒
(DT) DeskTop Symbol Set
0 1 2 3 4 5 6 7 8 9 A B C D E F
00
10
20 ! “ # $ % & ‘ ( ) * + , - . /
30 0 1 2 3 4 5 6 7 8 9 : ; < = > ?
40 @ A B C D E F G H I J K L M N O
50 P Q R S T U V W X Y Z [ \ ] ^ -
60 ‘ a b c d e f g h i j k l m n o
70 p q r s t u v w x y z { | } ~
▒
80
90
A0 ¶ § † ‡ © ®
¢ – — … fi fl
B0 “ “ µ ‰

o
þ

 
‘ ¬ ¦ =
C0 – ± ×
¼ ½ ¾ ¹ ² ³ /
D0 ( ) « » ‚ „ ‘ ¡ ¿ Pt ℓ £ ¥
¤
ƒ ß
E0 ª º æ Æ ð Ð ij IJ
t
t
œ Œ ø Ø þ Þ
F0 ‘ ‘ ˆ ¨ ˜ ˇ ˘
” ° ·
¯ , ˛
'
l

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
