Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
108 Class Series 2 Programmer’s Manual
STX KI GPIO Input
This command configures the GPIO input channels of the Applicator Interface Card; see
Appendix J for details.
Syntax:
<STX>KIffnspwww<CR>
ff
- 2 character function name abbreviation (e.g., PS [Print
Start], I1 [User Input 1], etc).
n
- Pin number, where 1 – 8 is the valid range.
s
- Signal type, where: L = Level; P = Positive Pulse;
and N = Negative Pulse
p
- Polarity, where: 0 = Active Low; and 1 = Active High
Where:
www
- 3 character filter pulse width, in milliseconds.
STX Kn NIC Reset
This command resets the NIC to factory defaults.
Syntax:
<STX>Knx
Where:
x
- Specifies the action, where:
F = Returns the NIC to the factory default settings; or,
H = Reports settings to host (wireless, only).
Address
Default Values
Wired Ethernet*
Default Values
Wireless Ethernet
IP
192.168.010.026 192.168.010.001
Subnet Mask
255.255.255.000 255.255.255.000
Gateway
000.000.000.000 000.000.000.000
* Prior to introduction of the Wireless Ethernet, 192.0.0.192
was the IP default value and the Subnet Mask was 0.0.0.0.

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
