Datamax E-Class Mark II Programmer's Manual

Appendix K – Maximum Row, Column, & Character Values; Print Resolutions & Widths; and, Module Identifiers & Allocations
Class Series 2 Programmer’s Manual 271
Column, Present, & Row Adjust Fine Tune Range
Printer
Resolution (DPI)
Column Adjust Fine Tune
Parameter Range (+/– dots)
Row & Present Adjust Fine Tune
Parameter Range (+/– dots)
203 -100 – 100 dots -100 – 2030 dots
300 -150 – 150 dots -150 – 3000 dots
400 -200 – 200 dots -200 – 4060 dots
600 -300 – 300 dots -300 – 6000 dots
Table K-3: Adjust Range per Print Resolution

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
