Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 41
STX KaW Write Data to RFID Tag
(Direct Mode – Generic Read/Write Interface)
This command instructs the RFID device to write data to the tag. It is expected that the
tag transponder will be within the read / write distance of the RFID programming device;
otherwise, a warning will occur and a warning message (Read / Write Fail) will be
displayed.
Syntax:
<STX>KaWAaaabbbcdee…e<CR>
Where:
Aaaa
-
Optional – for data in the ASCII format, followed by
the byte count (000-999).
bbb
-
HF – Starting block number (000  maximum block
number, which is dependent upon the
transponder manufacturer).
UHF – Should be 000.
c
-
Command 1. Reserved for Future (should be 0)
d
-
Command 2. Reserved for Future (should be 0)
ee…e
-
Data to be encoded on RFID tag (HF – the last used
block will be null-padded, if necessary).

UHF ASCII formats must be 8 or 12 characters; and,
UHF Hexadecimal formats must be 16 or 24
character pairs.
Sample:
<STX>KaW0000054455354[CR]
The sample above writes the data “TEST” at block zero.
STX Kb Backfeed Time Delay
This command controls the time a printed label is allowed to remain “presented” before
being retracted to the start of print position.
Syntax:
<STX>Kbnnn<CR>
Where:
nnn
-
Seconds/10

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
