Datamax E-Class Mark II Programmer's Manual

Appendix K –Maximum Row, Column, & Character Values; Print Resolutions & Widths; and, Module Identifiers & Allocations
270 Class Series 2 Programmer’s Manual
Print Resolutions and Maximum Width & Record Column Values
Print Resolution Dot Dimensions (nominal) Maximum Print Width
Maximum “gggg” Value
Model
DPI DPMM Inches Millimeters Dots Millimeters
Inch Metric
A-4212 203 8.0 .0043 x .0052 .11 x .13 832 104.1 410 1041
A-4310 300 11.8 .0027 x .0043 .07 x .11 1248 105.7 416 1057
A-4408 406 16.0 .0013 x .0018 .03 x .05 1664 104.1 410 1041
A-4606 600 23.6 .0008 x .0015 .02 x .04 2496 105.7 416 1057
A-6212 203 8.0 .0043 x .0052 .11 x .13 1344 168.1 662 1680
A-6310 300 11.8 .0027 x .0043 .07 x .11 1920 162.6 640 1626
EX2 203 8.0 .0043 x .0052 .11 x .13 832 104.1 410 1041
E-4205e & E-Class
Mark III (203DPI)
203 8.0 .0043 x .0052 .11 x .13 864 108.0 425 1080
E-4304e & E-Class
Mark III (300DPI)
300 11.8 .0027 x .0043 .07 x .11 1248 105.7 416 1046
MP Compact MarkII 203 8.0 .0043 x .0052 .11 x .13 864 108.0 425 1080
MP Compact MarkII 300 11.8 .0027 x .0043 .07 x .11 1248 105.7 416 1046
H-4212 & H-4212X 203 8.0 .0043 x .0052 .11 x .13 832 104.1 410 1041
H-4310 & H-4310X 300 11.8 .0027 x .0043 .07 x .11 1248 105.7 416 1046
H-4408 406 16.0 .0013 x .0018 .03 x .05 1664 104.1 410 1041
H-4606 & H-4606X 600 23.6 .0008 x .0015 .02 x .04 2496 105.7 416 1057
H-6210 & H-6212X 203 8.0 .0043 x .0052 .11 x .13 1344 168.1 662 1680
H-6308 & H-6310X 300 11.8 .0027 x .0043 .07 x .11 1920 162.6 640 1626
H-8308X 300 11.8 .0027 x .0043 .07 x .11 2560 216.7 853 2167
I-4206, I-4208,
I-4210 & I-4212
203 8.0 .0043 x .0052 .11 x .13 832 104.1 410 1041
I-4308 300 11.8 .0027 x .0043 .07 x .11 1248 105.7 416 1046
I-4406 406 16.0 .0013 x .0018 .03 x .05 1664 104.1 410 1041
I-4604 600 23.6 .0008 x .0015 .02 x .04 2496 105.7 416 1057
M-Class 4206 &
4210 Mark II
203 8.0 .0043 x .0052 .11 x .13 864 108.0 425 1080
M-Class 4308 Mark II 300 11.8 .0027 x .0043 .07 x .11 1248 105.7 416 1046
Table K-2: Print Widths, Resolutions, and Record Column Field Values

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
