Datamax E-Class Mark II Programmer's Manual

Class Series 2 Programmer’s Manual 145
7
Font Loading Command Functions
Introduction
The commands used for font loading are usually generated by font creation software;
however, the assigned font ID number command must be sent to the printer before the font
file. All Font Loading Commands begin with <ESC> (ASCII control character 27 [decimal]).
The downloaded font will be stored in the default module (refer to the <STX>X command) as
file type .dbm. The commands in the table below are listed in their order of appearance, top
to bottom, during font downloading. The <SOH>D command must be sent prior to
downloading a font.
Command Description
*c###D
Assign Font ID Number
)s#Wnn…n
Font Descriptor
*c#E
Character Code
(s#W
Character Download Data
Table 7-1: Font Loading Commands
*c###D Assign Font ID Number
This command is the first command required for downloading a font to either RAM or
Flash Memory modules. ESC represents the ASCII control character 27.
Syntax:
<ESC>*c###D
Where:
###
-
Is the font ID numbers 100-999 (000 – 099 are
reserved for resident fonts).

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
