Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 107
Sample:
<STX>KHB<CR>
The sample above returns results from the last dot check for
the number of elements tested, the number of the bad or
suspect dot(s), the total number of bad or suspect dots, and the
minimum, maximum, and average resistance and variance:
DOTCHECK RESULTS
DOTS TESTED GOOD 830 OF 832
BAD DOT LIST
143
144
TOTAL BAD DOTS: 2
MIN MAX AVG VAR
921 1640 1125 719

The process normally adds a few seconds to the power-up sequence; however, if the
printhead is invalid or extremely damaged, it could take a minute to complete.
STX KJ Assign Communication Port (MCL Command)
This command assigns a communication port for specific use. When activating MCL, all
ports are assigned to MCL; this command allows changes to that assignment.
Syntax:
<STX>KJpf<CR>
p
- Port ID: P = Parallel
S = Serial (A)
U = USB
N = Ethernet
L = Wireless
A = Serial (B)
Where:
f
- Flag: 1 = DPL
0 = MCL
Sample:
<STX>KJN1
The sample above forces the Ethernet port to bypass MCL and
go directly to DPL.

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
