Label Formatting Command Functions
Class Series 2 Programmer’s Manual 127
B Bar Code Magnification
This command provides a mechanism to specify bar codes greater than 36 dots (0 - 9, A
- Z in the field record). The value is reset to 1 at the start of every label and stays
active for the entire label or set to a new value.
Syntax:
Bnn
Where:
nn
-
Is a two digit decimal number indicating the
magnification value.
Sample:
<STX>L<CR>
D11
B01
1a9305000100030ABCD<CR>
B03
1a3105000700030ABCD<CR>
Q0001
E
The sample above instructs the printer to print two bar codes,
each 9 dots by 3 dots.
C Set Column Offset Amount
This command allows horizontal adjustment of the point where printing begins. The
printer is instructed to print label formats nnnn units to the right of the position that the
format specifies. This feature is useful when a single format is to be printed on labels
containing preprinted information.
Syntax:
Cnnnn
Where:
nnnn
-
Is a four-digit number for the column offset,
inches/100 or mm/10. The default is 0.
Sample:
<STX>L
C0050
141100001000100DATAMAX<CR>
The sample above shifts all format data 0.5 inches to the right,
unless the printer is in metric mode, (see Label Formatting
Command “m”).
If using preprinted labels where the placement of the preprint data varies from label to
label, the printed information may overlap the preprinted data.
