Class Series 2 Programmer’s Manual 167
Appendix B
Sample Programs
“C” Language Program
The following sample “C” program is included for reference. Figure B-1 shows the output
generated by this program.
/

DMX SERIES Sample C program

/
# include <stdio.h>
main ()
{
char

pcs = “590”;
char

desc = “10K OHM 1/4 WATT”;
fputs (“DMX Printer Test Program\n”, stdout);
fputs (“\x02L\n”, stdaux); /

STX L – Enter Label
Formatting

/
fputs (“H07\n” stdaux); /

Enter Heat Setting of 7

/
fputs (“D11\n”, stdaux); /

Set Width and Height Dot
Size

/
fprintf (stdaux, “191108010000025%s\n”,desc); /

Select smooth Font

/
fprintf (stdaux, “1a6210000000050%sPCS\n”, pcs); /

Select Bar code
type ‘a’

/
fputs (“E\n”, stdaux); /

End Label format mode and
print

/
}
10K OHM 1/4 WATT
Figure B-1: Sample Label

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
