Datamax E-Class Mark II Programmer's Manual

Appendix U – Display Icon Key and Control Panel Button Sequence Functions
310 Class Series 2 Programmer’s Manual
Control Panel Button Sequences
Three Button / Three LED Control Panel
Function Printer Mode Button Sequence
Pause Idle PAUSE
Feed / Clear Fault Idle FEED
Cancel Idle CANCEL
Soft Reset Idle PAUSE & CANCEL (or Long CANCEL)
Print Test Label Idle PAUSE & FEED
Print Configuration Label Idle FEED & CANCEL
Print Network Label Idle PAUSE, FEED, & CANCEL
Quick Calibration Idle Long FEED
Empty Calibration Idle Long PAUSE & FEED
Media Calibration * CANCEL
Reset Database to Configuration File * PAUSE & FEED
Menu / Setup * PAUSE
Reset firmware (but not Ethernet
parameters)
* PAUSE, FEED, & CANCEL
Reset firmware (and Ethernet
parameters)
* FEED & CANCEL
Hex Dump Mode Power-Up Hold FEED
Enter Boot Mode Power-Up Hold PAUSE & CANCEL
*Power “On” the printer then when the LEDs illuminate press and hold indicated the Button Sequence
until the LEDs extinguish.

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
