Datamax E-Class Mark II Programmer's Manual

Appendix G – Bar Code Details
236 Class Series 2 Programmer’s Manual
The following example prints an GS1 DataBar bar code with 2-D data:
<STX>L
D11
1W1k0000001500150R1002001234567890|123456-99/99/99
121100000000100Barcode W1k<CR>
E
Barcode W1k
The following example prints an GS1 DataBar Truncated bar code:
<STX>L
D11
1W1k0000001500150T1002001234567890
121100000000100Barcode W1k<CR>
E
Barcode W1k
The following example prints an GS1 DataBar Stacked bar code:
<STX>L
D11
1W1k0000001500150S1002001234567890
121100000000100Barcode W1k<CR>
E
Barcode W1k
The following example prints an GS1 DataBar Stacked Omni-Directional
bar code:
<STX>L
D11
1W1k0000001500150D1002001234567890
121100000000100Barcode W1k<CR>
E
Barcode W1k
The following example prints an GS1 DataBar Limited bar code:
<STX>L
D11
1W1k0000001500150L1001501234567890
121100000000100Barcode W1k<CR>
E
Barcode W1k
Syntax for the GS1 DataBar Expanded bar code (spaces added for readability):
a W1 k c d eee ffff gggg h i j m nn p…p | q…q
Where:

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
