Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 61
<STX>Kc
Parameter Name
Parameter
Pneumonic
Value /
Range
Units /
Interpretation
Menu Item (or Number)
(if available)
Command
Equivalent
Verifier Equipped
VE
A/Y, E, N/D
A or Y = Auto,
E = Enabled,
N or D = Disabled
Printer Options
<STX>KV
Verifier Type
VT
A, B, C, D
Reserved for future
use
N/A N/A
WiFi Security
(for firmware versions
13.99 and earlier. For
firmware versions 14.00
and later see Network
Setup parameter NE)
WS
A, K, S,
L, P, U
See Table 5-14. N/A N/A
WiFi Setup
(for firmware versions
13.99 and earlier. For
firmware versions 14.00
and later see Network
Setup parameter NE)
WE
A, C, F, I, L, M, N,
P, R, T, V, X
See Table 5-13. N/A N/A
1. Commands are provided for backward compatibility on EX2. The KcQQQ command will respond with the new command equivalent; see
associated new commands.
2. The EX2 will accept display-equipped module IDs (D & G) as command parameters for upward compatibility; query commands will result in
printer responses with module IDs that are non-display compatible, providing backward compatibility.
3. Present distance changes for EX2 will only be accepted if the Stop Location (SL) is set to “Host.”
Table 5-1: Configuration Set Commands

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
