Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 77
802.3 – Wired Ethernet Configuration Parameters – Identifier ‘WE’
The ‘WE’ sub-group contains network configuration parameters that apply only to the
Wired Ethernet (802.3 Specification) ethernet interface. No sub-groups are currently
defined for the ‘WE’ sub-group of configuration parameters, only item-value pairs.
The ‘Item-Value’ pairs within the ‘WE’ sub-group are defined by the following table:
Item
Number
Name Available
to User
(Y/N)
Value Type Description
1 DHCP Enable Y Boolean Indicates if the DHCP Protocol is to
be used to automatically obtain all
required network addresses.
Formally known as IP Discovery.
2 Static Printer IP
Address
Y String Static IP Address for the Printer in
dotted decimal notation.
3 Static Printer
Subnet Mask
Y String Static Subnet Mask for the Printer in
dotted decimal notation.
4 Static Printer
Default Gateway or
Router
Y String Static Default Gateway (Router) IP
Address in dotted decimal notation.
5 PHY Mode Y Decimal Defines the ethernet PHY Mode
(Auto, 10BaseT HD, etc.)
Auto-Negotiate = 0
10BaseT Half Duplex = 1
10BaseT Full Duplex = 2
100BaseT Half Duplex = 3
100BaseT Full Duplex = 4
6 PHY Advertise Mode Y Decimal Defines the ethernet PHY Advertise
mode.
Auto = 0
All Capabilities = 1
7 PHY Capabilities to
Advertise
Y Decimal Defines the ethernet PHY capabilities
to advertise.
Always = 0
8 MTU Y Decimal Defines the Maximum Transmission
Unit size for the wired interface.
Defaults to the DEFAULT MTU from
the ‘G’ sub-group.
802.11 – Wireless Ethernet - WIFI Configuration Parameters – Identifier ‘WIFI’
The ‘WIFI’ sub-group contains network configuration parameters that apply only to the Wireless Ethernet
(802.11 Specification) ethernet interface. Four (4) sub-groups are currently defined for the ‘WIFI’ sub-
group of configuration parameters and are as follows:
General WIFI Configuration Parameters – Identifier ‘G’
DPAC Version 1 – Identifier ‘DV1’
DPAC Version 2 (Veyron) – Identifier ‘DV2’
SILEX Version 1 – Identifier ‘SV1’

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
