Figure 107. Removing a power supply unit
Next step
Install the PSU or the PSU blank.
Installing a power supply unit
The procedure for installing AC and DC PSUs is identical.
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 For systems that support redundant PSU, ensure that both the PSUs are of the same type and have the same maximum output
power.
NOTE
: The maximum output power (shown in watts) is listed on the PSU label.
Step
Slide the PSU into the system until the PSU is fully seated and the release latch snaps into place.
Installing and removing system components
155
