NVDIMM-N memory module installation guidelines
The following are the recommended guidelines for installing NVDIMM-N memory modules:
• Each system supports memory congurations with 1, 2, 4, 6, or 12 NVDIMM-Ns.
• Supported congurations have dual processors and a minimum of 12x RDIMMs.
• Maximum of 12 NVDIMM-Ns can be installed in a system.
• NVDIMM-Ns or RDIMMs must not be mixed with LRDIMMs.
• DDR4 NVDIMM-Ns must be populated only on the black release tabs on processor 1 and 2.
• All slots on congurations 3, 6, 9, and 12 can be used, but a maximum of 12 NVDIMM-Ns can be installed in a system.
For more information on the supported NVDIMM-N congurations, see the NVDIMM-N User Guide at Dell.com/poweredgemanuals.
Table 43. Supported NVDIMM-N for dual processor congurations
Conguration Description Memory population rules
RDIMMs NVDIMM-N
Conguration 1 12x 16 GB RDIMMs, 1x
NVDIMM-N
Processor1 {A1, 2, 3, 4, 5, 6}
Processor2 {B1, 2, 3, 4, 5, 6}
Processor1 {A7}
Conguration 2 12x 32 GB RDIMMs, 1x
NVDIMM-N
Same for all 12x RDIMM
congurations. See
Conguration 1.
Processor1 {A7}
Conguration 3 23x 32 GB RDIMMs, 1x
NVDIMM-N
Processor1 {A1, 2, 3, 4, 5, 6, 7, 8,
9, 10, 11, 12}
Processor2 {B1, 2, 3, 4, 5, 6, 7, 8,
9, 10, 11}
Processor2 {B12}
Conguration 4 12x 16 GB RDIMMs, 2x
NVDIMM-Ns
Same for all 12x RDIMM
congurations. See
Conguration 1.
Processor1 {A7}
Processor2 {B7}
Conguration 5 12x 32 GB RDIMMs, 2x
NVDIMM-Ns
Same for all 12x RDIMM
congurations. See
Conguration 1.
Processor1 {A7}
Processor2 {B7}
Conguration 6 22x 32 GB RDIMMs, 2x
NVDIMM-Ns
Processor1 {A1, 2, 3, 4, 5, 6, 7, 8,
9, 10, 11}
Processor2 {B1, 2, 3, 4, 5, 6, 7, 8,
9, 10, 11}
Processor1 {A12}
Processor2 {B12}
Conguration 7 12x 16 GB RDIMMs, 4x
NVDIMM-Ns
Same for all 12x RDIMM
congurations. See
Conguration 1.
Processor1 {A7, A8}
Processor2 {B7, B8}
Conguration 8 22x 32 GB RDIMMs, 4x
NVDIMM-Ns
Same for all 12x RDIMM
congurations. See
Conguration 1.
Processor1 {A7, A8}
Processor2 {B7, B8}
