System board jumpers and connectors
Figure 120. System board jumpers and connectors
Table 52. System board jumpers and connectors
Item Connector Description
1. P_RG1_CP Right panel connector
2. J_WS_PWRBTN Power button connector
3. J_INTRUSION_DET1 Intrusion switch connector
4. J_FAN1U_2 Cooling fan connector
5. CPU2 Processor socket 2
6. J_BATT_SIG Battery signal connector
7. J_BATT_PWR Battery power connector
Jumpers and connectors 171
