Figure 29. Installing the intrusion switch module
Next steps
1. Reconnect all the cables to the power interposer board (PIB).
2. Follow the procedure listed in After working inside your system.
Drives
Removing a drive blank
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. If installed, remove the front bezel.
CAUTION: To maintain proper system cooling, drive blanks must be installed in all empty drive slots.
NOTE: The procedure to remove the drive blank is the same for Rear Accessed and Front Accessed configurations.
Steps
Press the release button, and slide the drive blank out of the drive slot.
Figure 30. Removing a drive blank
Installing and removing system components
41
