NOTE: To maintain optimal system health, Dell Technologies recommend checking and changing the filter every 3
months. Filters can be ordered from Dell.
Next steps
Replace the bezel filter.
Installing the bezel filter for Rear Accessed configuration
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Remove the front bezel.
Steps
1. Place the new filter in the bezel cavity under the filter bracket. Ensure that the filter is smooth and flush in the allowed
cavity.
2. Align the filter bracket with painted surface facing the filter and align the bracket to the guides on the bezel. Place the
bracket on the bezel for the magnets to secure in place.
Figure 17. Installing the front bezel filter for Rear Accessed configuration
Next steps
Install the front bezel.
System cover
Removing the system cover
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
Installing and removing system components
31
