Figure 74. Installing expansion card in Riser 2 and 3
Next steps
1. Follow the procedure listed in After working inside your system.
2. Install any device drivers required for the card as described in the documentation for the card.
NOTE:
While replacing faulty storage controller or NIC or the GPU card with the same type of card, after you power on the
system, the new card automatically updates to the same firmware and configuration of the faulty one. For more information
about the Part replacement configuration, see the Lifecycle Controler User's Guide at https://www.dell.com/idracmanuals
Optional BOSS S1 card
Removing the BOSS S1 card
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
NOTE: The procedure to remove the BOSS S1 card is the same for Rear Accessed and Front Accessed configurations.
Steps
Holding the blue tag, pull the M.2 BOSS card away from the system board connector.
Installing and removing system components
79
