Figure 33. Installing a drive carrier
Next steps
If removed, install the front bezel.
Removing the drive from the drive carrier
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
Steps
1. Using a Phillips #1 screwdriver, remove the screws from the slide rails on the drive carrier.
NOTE:
If the hard drive carrier has Torx screw , use Torx 6 (for 2.5-inch drive).
2. Lift the drive out of the drive carrier.
44
Installing and removing system components
