Dell PowerEdge C6600 - Cooling Fans; Removing a 80 mm Fan

Figure 29. Installing the mid top cover
Next steps
Follow the procedure listed in After working inside your system.
Cooling fans
Removing a 80 mm fan
Prerequisites
WARNING: Do not attempt to operate the system without the 80 mm fans.
WARNING: The 80 mm fan spins for some time after the system is powered off. Allow the 80 mm fan to stop
spinning before removing it from the system.
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
1. Using the Phillips 2 screwdriver, remove the screw securing the 80 mm fan to the system.
NOTE:
Observe the routing of the cables on the chassis as you remove them from the system. Route these cables
properly when you replace them to prevent the cables from being pinched or crimped.
2. Disconnect the fan cable from the connector on the fan cage and pull the fan out of the fan cage.
Installing and removing system components
33
