Figure 38. Removing the 40 mm fan cage
Next steps
1. Installing the 40 mm fan cage.
Installing the 40 mm fan cage
Prerequisites
WARNING: Do not attempt to operate the system without the cooling fans.
NOTE: Observe the routing of the cables when removing them from the system. Route these cables properly when you
replace them to prevent the cables from being pinched or crimped.
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedures listed in Before working inside your system.
3. Remove the system cover
Steps
Align the fan cage pins with the pin holders on the fan cage holder. Lower down the fan cage until all four pins are secured in
place on the holder.
42
Installing and removing system components
