System weight
Table 16. PowerEdge C6600 system weight
System configuration Maximum weight (with all drives/SSDs)
8 x E3.s 41.1 kg (90.60 pound)
16 x 2.5-inch SAS/SATA 42.5 kg (93.69 pound)
16 x 2.5-inch NVMe 41.8 kg (92.15 pound)
Diskless 39.2 kg (86.42 pound)
Table 17. PowerEdgesystemweight handling recommendations
Chassis weight Description
40 pounds - 70 pounds Recommend two person to lift
70 pounds- 120 pounds Recommend three person to lift
≥ 121 pounds Recommend to use a server-lift
Drives
The PowerEdge C6600 system supports:
● 16 x 2.5-inch hot-swappable SAS/SATA/NVMe drives.
● 8 x E3.s NVMe SSD drives.
NOTE:
For more information about how to hot swap NVMe PCIe SSD U.2 device, see the Dell Express Flash NVMe PCIe
SSD User's Guide at https://www.dell.com/support >Browse all Products > Data Center Infrastructure > Storage
Adapters & Controllers > Dell PowerEdge Express Flash NVMe PCIe SSD > Documentation > Manuals and
Documents.
PSU specifications
The PowerEdge C6600 system supports up to two AC or DC power supply units (PSUs).
Table 18. PSU specifications
PSU Class Heat
dissipation
(maximum)
(BTU/hr)
Frequency
(Hz)
Voltage AC DC Current
(A)
High line
wattage
Low line
wattage
3200 W NA 12000 BTU/hr 50/60 Hz 277 V AC 3200 W NA NA 13.0 A
3200 W NA 12000 BTU/hr NA 336 V DC NA NA 3200 W 11.5 A
2800 W Titanium 10500 BTU/hr 50/60 Hz 200-240 V AC 2800 W NA NA 15.6 A
2800 W NA 10500 BTU/hr NA 240 V DC NA NA 2800 W 13.6 A
2400 W Platinum 9000 BTU/hr 50/60 Hz 100-240 V AC 2400 W 1400 W NA 16-13.5A
2400 W NA 9000 BTU/hr NA 240 V DC NA NA 2400 W 11.2 A
1800 W Titanium 6750 BTU/hr 50/60 Hz 200-240 V AC 1800 W NA NA 10 A
1800 W NA 6750 BTU/hr NA 240 V DC NA NA 1800 W 8.2 A
NOTE: Heat dissipation is calculated using the PSU wattage rating.
92 Technical specifications
