Dell PowerEdge C6600 - Installing a Power Supply Unit

Figure 52. Removing a power supply unit
Next steps
Replace the PSU.
Installing a power supply unit
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. For systems that support redundant PSU, ensure that both the PSUs are of the same type and have the same maximum
output power.
NOTE: The maximum output power (shown in watts) is listed on the PSU label.
Steps
Slide the PSU into the PSU bay until the release latch snaps into place.
54
Installing and removing system components
