Starting Milling
32
Chapter 2 Milling
Use a torque screwdriver to loosen the screws holding the pin‑type workpiece in position.
Mount the pin‑type workpiece on the pin‑type workpiece adapter.
Make sure the recessed portion of the pin-type workpiece is oriented downward, align the protrusion of the pin-type
workpiece adapter with this recessed portion, and then insert the workpiece all the way in.
Tighten the screws using a torque screwdriver.
Tighten the screws until they click.
MEMO
Use the included spare screws when a screw is lost or worn.
