Starting Milling
31
Chapter 2 Milling
2. Mount the workpiece on the pin‑type workpiece adapter.
Mounting layout examples
The gure shows examples of the maximum number of workpieces that can be attached according to size. It also shows the layouts of
these workpieces. Workpiece sizes are limited by the number of workpieces mounted in the machine, and the number of mountable
workpieces is limited by the size of the workpieces mounted in the machine.
L ≤ 20 mm
20 mm < L ≤ 50 mm
50 mm < L
