Starting Milling
30
Chapter 2 Milling
Turn the adapter cap in the direction indicated by the arrows to attach it to the screws.
Use a torque screwdriver to tighten the screws in the positions shown in the gure. (4 locations)
Tighten the screws until they click.
Also, to secure the adapter evenly, after tightening the screw in one location, tighten the screw that is oriented diagonally
across from it.
