Microsoft SAC support Setup the Digi CM Unit for SAC support

Digi CM User Guide 91

6 Set other fields as appropriate.

7 Click Save & apply.

8 Configure serial port communication settings, by doing the following:

a. Choose Serial port parameters from the menu.

b. Adjust settings as required. This includes ensuring that the Baud rate matches the setting on

the Windows Server 2003 serial port and Flow control is set to None. Ignore the DTR behavior

field.

c. Click Save & apply.
