Digi XBee SX User Manual

Operate in API mode API frames
XBee®/XBee-PRO SX RF Module User Guide
127
n 64-bit address: 0x0013A200 01238400
n Source endpoint: 0xE8
n Destination endpoint: 0xE8
n Cluster ID: 0x11
n Profile ID: 0xC105
n Payload: TxData
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x1A
Frame type 3 0x11
Frame ID 4 0x01
64-bit destination address MSB 5 0x00
6 0x13
7 0xA2
8 0x00
9 0x01
10 0x23
11 0x84
LSB12 0x00
Reserved
13
0xFF
14
0xFE
Source endpoint 15 0xE8
Destination endpoint 16 0xE8
Cluster ID 17 0x00
18 0x11
Profile ID 19 0xC1
20 0x05
Broadcast radius 21 0x00
Transmit options 22 0x00
