AT commands I/O settings commands
XBee®/XBee-PRO SX RF Module User Guide
90
Parameter Description
1 RSSI PWM0 output
2 PWM0 output
3 Digital input
4 Digital output, low
5 Digital output, high
Default
1
P1 (DIO11/PWM1 Configuration)
Sets or displays the DIO11/PWM1 configuration (pin 8).
When configured as a PWM1 output, you can use M1 to set the PWM duty cycle.
Parameter range
0 - 5
0 - 6
Parameter Description
0 Disabled
1 32.768 kHz clock output
2 PWM1 output
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
P2 (DIO12 Configuration)
Sets or displays the DIO12 configuration (pin 5).
Parameter range
0, 3 - 6
Parameter Description
0 Disabled
