Regulatory information FCC (United States)
XBee®/XBee-PRO SX RF Module User Guide 189
XBee SX antenna options (13 dBm maximum RF power)
The following tables cover the antennas that are approved for use with the XBee SX RF Module. If applicable, the tables show the required cable loss
between the device and the antenna.
Dipole antennas
All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
Part number Type Connector Gain
Required antenna cable loss
Application
A09-HSM-7 Straight half-wave RPSMA 2.1 dBi
0.4 dB
Fixed/mobile
A09-HASM-675 Articulated half-wave RPSMA 2.1 dBi
0.4 dB Fixed/mobile
A09-HABMM-P5I Swivel half wave with 5" pigtail MMCX 2.1 dBi
0.4 dB Fixed/mobile
A09-HBMM-P5I Straight half-wave with 6" pigtail MMCX 2.1 dBi
0.4 dB Fixed/mobile
A09-HASM-7* Articulated half-wave RPSMA 2.1 dBi
0.4 dB
Fixed
A09-HRSM* Right angle half-wave RPSMA 2.1 dBi
0.4 dB
Fixed
A09-HG* Glass mounted half-wave RPSMA 2.1dBi
0.4 dB
Fixed
A09-HATM* Articulated half-wave RPTNC 2.1 dBi
0.4 dB
Fixed
A09-H* Half-wave dipole RPSMA 2.1 dBi
0.4 dB
Fixed
Yagi antennas
All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
Part number Type Gain Connector Required antenna cable loss Application
A09-Y6NF* 2 element Yagi 6.1 dBi N
- Fixed/mobile
A09-Y7NF* 3 element Yagi 7.1 dBi N
- Fixed/mobile
