Technical specifications Regulatory conformity summary
XBee®/XBee-PRO SX RF Module User Guide
14
Regulatory conformity summary
This table describes the agency approvals for the devices.
The Australia, New Zealand and Brazil certified devices are separate variants from the USA and
Canada approved device.
Country Approval
XBee-PRO SX XBee SX
United States FCC ID: MCQ-XBPSX FCC ID: MCQ-XBSX
Canada IC: 1846A-XBPSX IC: 1846A-XBSX
Australia RCM RCM
New Zealand R-NZ
Brazil ANATEL: 05774-16-01209 ANATEL: 05776-16-01209
Power requirements
The following table describes the power requirements for the XBee/XBee-PRO SX RF Module.
Specification Condition XBee SX value XBee-PRO SX value
Supply voltage range 2.4 to 3.6 VDC 2.6 to 3.6 VDC
Typical supply voltage 3.3 V
Receive current VCC = 3.3 V 40 mA 40 mA
Transmit current VCC = 3.3 V 55 mA @ 13 dBm 900 mA @ 30 dBm
VCC = 3.3 V 45 mA @ 10 dBm 640 mA @ 27 dBm
VCC = 3.3 V 35 mA @ 0 dBm 350 mA @ 21.5 dBm
Sleep current VCC 3.3 V, temperature = 25 °C 2.5 µA 2.5 µA
Networking specifications
The following table provides the networking specifications for the device.
Specification Value
Modulation Gaussian Frequency Shift Keying (GFSK)
Spreading
technology
Frequency Hopping Spread Spectrum (FHSS)
Supported network
topologies (software
selectable)
Peer-to-peer (master/slave relationship not required), point-to-point/point-
to-multipoint, mesh
