Page #88 background imageLoading...
Page #88 background image
AT commands I/O settings commands
XBee®/XBee-PRO SX RF Module User Guide
88
Parameter Description
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D7 (DIO7/CTS)
Sets or displays the DIO7/CTS configuration (pin 25).
Parameter range
0, 1, 3 - 7
Parameter Description
0 Disabled
1
CTSflow control
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
6 RS-485 Tx enable, low Tx (0 V on transmit, high when idle)
7 RS-485 Tx enable high, high Tx (high on transmit, 0 V when idle)
Default
0x1
D8 (DIO8/SLEEP_REQUEST)
Sets or displays the DIO8/DTR/SLP_RQ configuration (pin 10).
This line is also used with Pin Sleep, but pin sleep ignores the D8 configuration. It is always used to
control pin sleep, regardless of configuration of D8.
Parameter range
0, 1, 3 - 5
