Technical specifications Performance specifications
XBee®/XBee-PRO SX RF Module User Guide
15
Specification Value
Encryption
Optional 256-bit Advanced Encryption Standard (AES) cipher block chaining
(CBC) Encryption. Use the EE command to enable encryption. Use the KY
command to set the encryption key.
Performance specifications
The following table describes the performance specifications for the devices.
Specification Condition XBee value
XBee-PRO
value
Frequency range ISM 902 to 928 MHz
RF data rate
(software selectable)
Low data rate 10 kb/s
Middle data rate 110 kb/s
High data rate 250 kb/s
Transmit power
(software selectable)
Up to 13 dBm Up to 30
dBm
1
New Zealand
specific
Up to 13 dBm, at the high data rate
(BR 2) it is capped at 7.5 dBm
Maximum data
throughput
High data rate 120 kb/s
Channels 10 hopping sequences share 50 frequencies
Available channel
frequencies
Low/middle data
rate
101
2
High data rate 50
Rural range line of
sight
Low data rate Up to 14.5 km (9 mi) Up to 105
km (65 mi)
3
Urban range line of
sight
Low data rate Up to 2.5 km (1.5 mi) Up to 18 km
(11 mi)
4
1
30 dBm typical at 3.3 V and above. Maximum power will decrease at lower voltages. For more information on
adjustable power levels, see PL (TX Power Level).
2
The device hops on 50 channels selected using the CM command, from 101 available frequencies. For more
details, see CM (Channel Mask).
3
We estimate rural ranges based on a 14.5 km (9 mi) range test with dipole antennas.
4
Range estimated assuming that the urban noise floor is approximately 15 dB higher than rural. The actual
range depends on the setup and level of interference in your location.
