Digi XBee SX User Manual

AT commands I/O settings commands
XBee®/XBee-PRO SX RF Module User Guide
87
Parameter Description
0 Unmonitored digital input
1 N/A
2 ADC
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D5 (DIO5/ASSOCIATED_INDICATOR)
Sets or displays the DIO5/ASSOCIATED_INDICATOR configuration (pin 28).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
Associate LED indicator - blinks when associated
2 N/A
3 Digital input
4 Digital output, default low
5 Digital output, default high
Default
1
D6 (DIO6/RTS)
Sets or displays the DIO6/RTS configuration (pin 29).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
RTS flow control
