AT commands I/O settings commands
XBee®/XBee-PRO SX RF Module User Guide
95
Bit I/O line Module pin
5
DIO6/RTS
29
6 DIO8/SLEEP_REQUEST 9
7
DIO14/DIN/CONFIG
4
8 DIO5/ASSOCIATE 28
9
DIO9/On/SLEEP
26
10 DIO12 5
11 DIO10/RSSI/PWM0 7
12 DIO11/PWM1 8
13
DIO7/CTS
25
14 DIO13/DOUT 3
15 DIO15/SPI_MISO 17
16 DIO16/SPI_MOSI 16
17 DIO17/SPI_
SSEL
15
18 DIO18/SPI_SCLK 14
19
DIO19/SPI_ATTN
12
Parameter range
0 - 0xFFFFF (bit field)
Default
0xFFFFF
M0 (PWM0 Duty Cycle)
The duty cycle of the PWM0 line (pin 7).
Use the P0 command to configure the line as a PWM output.
Parameter range
0 - 0x3FF
Default
0
M1 (PWM1 Duty Cycle)
The duty cycle of the PWM1 line (pin 8).
Use the P1 command to configure the line as a PWM output.
Parameter range
0 - 0x3FF
