Operate in API mode API frames
XBee®/XBee-PRO SX RF Module User Guide
148
Node Identification Indicator frame - 0x95
Description
A device receives this frame when:
n it transmits a node identification message to identify itself
n AO = 0
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
specifications.
Frame data
fields Offset Description
Frame type 3 0x95
64-bit source
address
4-11
MSB first, LSB last. The sender's 64-bit address.
Reserved
12-13 Reserved.
Receive
options
14
Bit field:
Ignore all other bits
Reserved
15-16
Reserved.
64-bit remote
address
17-24 Indicates the 64-bit address of the remote device that transmitted the
Node Identification Indicator frame.
NI string
25-26 Node identifier string on the remote device. The NI string is terminated
with a NULL byte (0x00).
Reserved
27-28
Reserved.
Device type
29
0=Coordinator
1=Normal Mode
2=End Device
For more options, see NO (Network Discovery Options).
Source event
30 1=Frame sent by node identification pushbutton event.
Digi Profile ID
31-32 Set to the Digi application profile ID.
Digi
Manufacturer
ID
33-34 Set to the Digi Manufacturer ID.
Digi DD value
(optional)
35-38
Reports the DD value of the responding device. Use the NO command to
enable this field.
RSSI (optional) 39 Received signal strength indicator. Use the NO command to enable this
field.
