Operate in API mode API frames
XBee®/XBee-PRO SX RF Module User Guide
149
Example
If you press the commissioning pushbutton on a remote device with 64-bit address
0x0013A200407402AC and a default NI string sends a Node Identification, all devices on the network
receive the following node identification indicator:
A remote device with 64-bit address 0x0013A200407402AC and a default NI string sends a Node
Identification, all devices on the network receive the following node identification indicator:
If you press the commissioning button on a remote router device with 64-bit address 0x0013A200
40522BAA, 16-bit address 0x7D84, and default NI string, devices on the network receive the node
identification indicator.
Frame data fields Offset Example
Start delimiter 0 0x7E
Length
MSB 1 0x00
LSB 2 0x25
Frame type 3 0x95
64-bit source address MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x74
10 0x02
LSB 11 0xAC
Reserved
12
0xFF
13
0xFE
Receive options 14 0xC2
Reserved 15 0xFF
16 0xFE
