AT commands I/O settings commands
XBee®/XBee-PRO SX RF Module User Guide
84
Parameter Description
1 API Mode Without Escapes. The device packetizes all UART input and output data in API
format, without escape sequences.
2 API Mode With Escapes. The device is in API mode and inserts escaped sequences to
allow for control characters. The device passes XON (0x11), XOFF (0x13), Escape
(0x7D), and start delimiter 0x7E as data.
Parameter Description
0 API disabled (operate in Transparent mode)
1 API enabled
2 API enabled (with escaped control characters)
Default
0
AO (API Options)
The API data frame output format for RF packets received.
Use AO to enable different API output frames.
Parameter range
0 - 2
Parameter Description
0 API Rx Indicator - 0x90, this is for standard data frames.
1 API Explicit Rx Indicator - 0x91, this is for Explicit Addressing data frames.
2 XTend DigiMesh API Rx Indicator - 0x80
Default
0
I/O settings commands
The following AT commands are I/O settings commands.
D0 (DIO0/AD0)
Sets or displays the DIO0/AD0 configuration (pin 33).
Parameter range
0 - 5
