Operate in API mode API frames
XBee®/XBee-PRO SX RF Module User Guide
140
Frame data fields Offset Example
Length MSB 1 0x00
LSB 2 0x11
Frame type 3 0x80
64-bit source address MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x52
10 0xC5
LSB 11 0x07
RSSI 12 0x28
Options 13 0x01
Received data
14 0x52
15 0x78
16 0x44
17 0x61
18 0x74
19 0x61
Checksum 20 0xFF
