Work with networked devices Test links between adjacent devices
XBee®/XBee-PRO SX RF Module User Guide
162
Button
presses
Sleep
configuration
and sync
status Action
1 Not configured
for sleep
Immediately sends a Node Identification broadcast transmission.
All devices that receive this transmission blink their Associate LED rapidly
for one second.
All devices in API operating mode that receive this transmission send a
Node Identification Indicator frame (0x95) out their UART.
1 Configured for
asynchronous
sleep
Wakes the device for 30 seconds.
Immediately sends a Node Identification broadcast transmission.
All devices that receive this transmission blink their Associate LED rapidly
for one second.
All devices in API operating mode that receive this transmission send a
Node Identification Indicator frame (0x95) out their UART.
1 Configured for
synchronous
sleep
Wakes the module for 30 seconds or until the synchronized network goes
to sleep.
Queues a Node Identification broadcast transmission that it sends at the
beginning of the next network wake cycle.
All devices that receive this transmission blink their Associate LED rapidly
for one second.
All devices in API operating mode that receive this transmission send a
Node Identification Indicator frame (0x95) out their UART.
2 Not configured
for
synchronous
sleep
No effect.
2 Configured for
synchronous
sleep
Causes a node configured with sleeping router nomination enabled to
immediately nominate itself as the network sleep coordinator. For more
information, see SO (Sleep Options).
4 Any Sends an RE command to restore device parameters to default values.
Use the Commissioning Pushbutton
Use the CB command to simulate button presses in software. Send CB with a parameter set to the
number of button presses to perform. For example, if you send ATCB1, the device performs the action
(s) associated with a single button press.
Node Identification Indicator frame - 0x95 is similar to Remote Command Response frame - 0x97 – it
contains the device’s address, node identifier string (NI command), and other relevant data. All
devices in API operating mode that receive the Node Identification Indicator frame send it out their
UART as a Node Identification Indicator frame.
If you enable the Commissioning Pushbutton during sleep, it increases the sleeping current draw,
especially in Asynchronous pin sleep (SM = 1) mode. When asleep, hold down the Commissioning
Pushbutton for up to two seconds to wake the device from sleep, then issue the two or four button
presses.
