Regulatory information FCC (United States)
XBee®/XBee-PRO SX RF Module User Guide 187
Part number Type Gain Connector Required antenna cable loss Application
A09-F3TM* Fiberglass base station 3.1 dBi RPTNC - Fixed
A09-F4TM* Fiberglass base station 4.1 dBi RPTNC - Fixed
A09-F5TM* Fiberglass base station 5.1 dBi RPTNC - Fixed
A09-F6TM* Fiberglass base station 6.1 dBi RPTNC 0.9 dB Fixed
A09-F7TM* Fiberglass base station 7.1 dBi RPTNC 1.9 dB Fixed
A09-F8TM* Fiberglass base station 8.1 dBi RPTNC 2.9 dB Fixed
A09-W7* Wire base station 7.1 dBi RPN 1.9 dB Fixed
A09-W7SM* Wire base station 7.1 dBi RPSMA 1.9 dB Fixed
A09-W7TM* Wire base station 7.1 dBi RPTNC 1.9 dB Fixed
Dome antennas
All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
Part number Type Gain Connector Required antenna cable loss Application
A09-D3PNF* Omnidirectional permanent mount 3.0dBi N 0.4 dB Fixed/mobile
A09-D3NF* Omnidirectional magnetic mount 3.0 dBi N 0.4 dB Fixed/mobile
A09-D3PTM* Omnidirectional permanent mount 3.0 dBi RPTNC 0.4 dB Fixed/mobile
A09-D3PSM* Omnidirectional permanent mount 3.0 dBi RPSMA 0.4 dB Fixed/mobile
Monopole antennas
All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
