MTG2000 Trunk Gateway User Manual V| Dinstar
116
Belong to
Parameter
Explanation
SNMP Version
SNMP Version
v1/v2c/v3
SNMP Listen Port
SNMP Listen
Port
The device SNMP listening port is 161 by
default, and it will take effect after
modification.
User
Configuration
User
Same as the user name set on the SNMP
server.
Auth Type
MD5/SHA, consistent with the setting on the
SNMP server.
Auth Password
The password is consistent with the setting
on the SNMP server.
Privacy Type
DES/AES/AES128, consistent with the
setting on the SNMP server.
Privacy
Password
The password is the same as that set on the
SNMP server.
Group
Configuration
Group
Custom group name .
Community
The community configured above.
View
Configuration
View Name
Custom
View Type
included/excluded
View Subtree
The Root OID of the Mib Subtree, in the
format x.x.x.x.x. If there is only one x, the
format is x.
View Mask
The mask and the OID of the mib tree are
expressed in hexadecimal to determine the
range of a view. After translating into binary,
each bit corresponds to a bar in the OID. 1
means exact match, and 0 means general.
Access
Configuration (v3)
Group
Choose a group name from the ones
configured above.
Sec. Level
Authnopriv/authpriv, the encryption type and
encryption password will be empty.
When the security level is authpriv, the
encryption type and encryption password
will be empty.
Read
Select from the configured views above.
Write
Select from the configured views above.
Notify
Select from the configured views above.
Trap
Configuration
Trap Flag
V1/V2c/inform
Trap IP
The address of SNMP trap.
