54 ECY-303 Preloaded Applications
Parameter Description
Input 1 Configuration
Unconfig
– Hardware Input is not used.
SpaceTemp
– Space temperature sensor.
FanStatus
– Digital fan status input.
OccDetect
– Motion detection sensor.
AuxiliaryContact
– Auxiliary contact.
EconEnable
– Economizer enable input.
Window
– Window contact.
Input 2 Configuration
Unconfig
– Hardware Input is not used.
SpOffset
– Setpoint offset potentiometer.
FanStatus
– Digital fan status input.
OccDetect
– Motion detection sensor.
AuxiliaryContact
– Auxiliary contact.
EconEnable
– Economizer enable input.
Window
– Window contact.
Input 3 Configuration
Unconfig
– Hardware Input is not used.
ReturnTemp
– Return temperature sensor.
FanStatus
– Digital fan status input.
OccDetect
– Motion detection sensor.
AuxiliaryContact
– Auxiliary contact.
EconEnable
– Economizer enable input.
Window
– Window contact.
Input 4 Configuration
Unconfig
– Hardware Input is not used.
DischTemp
– Discharge temperature sensor.
FanStatus
– Digital fan status input.
OccDetec
t – Motion detection sensor.
AuxiliaryContact
– Auxiliary contact.
EconEnable
– Economizer enable input.
Window
– Window contact.
Input 5 Configuration
Unconfig
– Hardware Input is not used.
OutdoorTemp
– Outdoor temperature sensor.
FanStatus
– Digital fan status input.
OccDetect
– Motion detection sensor.
AuxiliaryContact
– Auxiliary contact.
EconEnable
– Economizer enable input.
Window
– Window contact.
Input 6 Configuration
Unconfig
– Hardware Input is not used.
FanCurrent
– Analog fan current input.
ReturnHumid
– Return humidity sensor.
DischHimid
– Discharge humidity sensor.
SpaceHumid
– Space humidity sensor.
OutdoorHumid
– Outdoor humidity sensor.
Input 7 Configuration
Unconfig
– Hardware Input is not used.
SpaceCO2
– Space CO
2
sensor.
ReturnHumid
– Return humidity sensor.
DischHimid
– Discharge humidity sensor.
SpaceHumid
– Space humidity sensor.
OutdoorHumid
– Outdoor humidity sensor.
Input 8 Configuration
Unconfig
– Hardware Input is not used.
ReturnCO2
– Return CO
2
sensor.
ReturnHumid
– Return humidity sensor.
DischHimid
– Discharge humidity sensor.
SpaceHumid
– Space humidity sensor.
OutdoorHumid
– Outdoor humidity sensor.
Input 6 Signal Type
Input 7 Signal Type
Input 8 Signal Type
0-10V
2-10V
4-20mA
0-5V
Temperature Sensors Type
10K Type 2
10K Type 3
PT1000
NI1000@0C
NI1000@22C
Temperature Sensors Units Choose between Degrees Celcius or Fahrenheit.
CO
2
Range Maximum Value
Enter the maximum scaling of UI7 or UI8 when configured for SpaceCO2 or ReturnCO2.
The range of the input can be configured using UI7 Signal Type or UI8 Signal Type.
CO
2
Range Minimum Value
Enter the minimum scaling of UI7 or UI8 when configured for SpaceCO2 or ReturnCO2.
The range of the input can be configured using UI7 Signal Type or UI8 Signal Type.
Configuring the Preloaded Applications
