67ECY-303 Preloaded Applications
Input Configuration Tables
Input Number (BACnet object) Default Valid Choices Parameter Description
UI1 (MSV 24)
1 Unconfig Not configured
x 2 SpaceTemp Room temperature sensor
3 FanStatus Fan powered box status
4 OccDetect Occupancy detection
5 AuxilliaryContact Auxiliary Contact
6 EconEnable Economizer Enable
7 Window Window contact
UI2 (MSV 25)
1 Unconfig Not configured
x 2 SpOffset Setpoint Offset
3 FanStatus Fan powered box status
4 OccDetect Occupancy detection
5 AuxilliaryContact Auxiliary Contact
6 EconEnable Economizer Enable
7 Window Window contact
UI3 (MSV 26)
1 Unconfig Not configured
x 2 ReturnTemp Return temperature sensor
3 FanStatus Fan powered box status
4 OccDetect Occupancy detection
5 AuxilliaryContact Auxiliary Contact
6 EconEnable Economizer Enable
7 Window Window contact
UI4 (MSV 27)
1 Unconfig Not configured
x 2 DischTemp Discharge air temperature sensor
3 FanStatus Fan powered box status
4 OccDetect Occupancy detection
5 AuxilliaryContact Auxiliary Contact
6 EconEnable Economizer Enable
7 Window Window contact
UI5 (MSV 28)
1 Unconfig Not configured
x 2 OutdoorTemp Outdoor air temperature sensor
3 FanStatus Fan powered box status
4 OccDetect Occupancy detection
5 AuxilliaryContact Auxiliary Contact
6 EconEnable Economizer Enable
7 Window Window contact
UI6 (MSV 29)
x 1 Unconfig Not configured
2 FanCurrent Fan Current
3 ReturnHumid Return humidity sensor
4 DischHumid Discharge humidity sensor
5 SpaceHumid Room humidity sensor
6 OutdoorHumid Outdoor humidity sensor
UI7 (MSV 30)
x 1 Unconfig Not configured
2 SpaceCO2 Room CO
2
sensor
3 ReturnHumid Return humidity sensor
4 DischHumid Discharge humidity sensor
5 SpaceHumid Room humidity sensor
6 OutdoorHumid Outdoor humidity sensor
UI8 (MSV 31)
x 1 Unconfig Not configured
2 ReturnCO2 Return CO
2
sensor
3 ReturnHumid Return humidity sensor
4 DischHumid Discharge humidity sensor
5 SpaceHumid Room humidity sensor
6 OutdoorHumid Outdoor humidity sensor
Allure EC-Smart-Vue Screen-by-Screen Guide
